Features And Specifications:

• Pattern: Classic carbon fiber.
• Color: Black.
• Finish: Satin.
• Roll Sizes: 5ft x 1ft, 2ft, 3.3ft, 6.5ft, 10ft, 13ft, 16ft, 33ft, 49ft, and 59ft.
• Durable and long-lasting.
• Water and weatherproof.
• Anti-corrosion, anti-scratch, and anti-stain.
• Heat and UV resistant.
• Medium stretchable.
• Easily conforms to curves and contours.
• Easy flawless wrapping.
• High-quality solvent-based adhesive.

Structure

Material

• Made from high-quality polymeric calendared vinyl for lasting durability.

• Features beautiful, eye-catching colors that stand out.
• Repositionable and slideable, so you can adjust as needed.

Medium Stretchable

The Maximum is 30 %

Functions

▲ Standard Size & Appearance

Classification		Unit	Spec	Remark
Thickness	Top protected film	um	36±2%	PET
	Surface materials	um	120±2%	High-grade PVC-Polymeric
	Glue	um	30±2%	High-quality Solvent-based
	Plastic liner	um	130±2(plastic)	－
Surface		－	Opaque	－
Width		mm	1520±0. 01%	5ft
Length		mm	1800±1%	59ft



Physical properties

▲ General Properties

Features		Test Method	Results
Release force N/25mm		Temperature 25℃ and Humidity 50%	0.23
Initial tack g/25mm		under 26℃ and 64%, GB31125-2014	850
Peel Strength N/25mm		25℃and 42%, GB/T2792-1998	7.51
Holding power(h)		25℃ and 50%, GB/T4851-1998	120
Shelf life		stored in +15°C to +20°C, relative humidity 50%, in original package, away from direct sunlight, clean and dry place	2 years
Application temperature		/	+20℃ to +30℃
Service temperature		/	-50℃ to +110℃
Time limits		Must use it within 3 months after receiving the wrap film	3 months
Durability		Vertical exposure (Black)	3 years
Durability		Vertical exposure (Colors)	2 years
Aging Test 1		7 days under 65°C	No adhesive residue with heat
Aging Test 2		10 days under 65°C	No adhesive residue without heat
Shrinkage		/	less than 4%



Recommended application tools: Squeegee, buffer, knife, masking tape, heat gun, magnets, gloves, IRR thermometer, sprayer, towel, and installation liquid
Application method: Standard methods for calendered films. No overstretching and overheating and Post heating is necessary.
Post-heating temperature: 110°C flat surfaces, 130°C curves, and overlaps
Aftercare: PH neutral, Avoid wax or solvents

CAUTION!

 1. We will peel off the protection layer before shipment if your order is 1m,3m or 5m in order to make the vinyl good for shipping.

 2. The images, colors, and finishes on the screen are approximate. For the real representation of the product always check the color swatch.

3. Most vinyl wraps are directional. Install the vinyl in the same direction across all panels. Applying the material in different directions can cause visible color differences due to light reflection.
